Modacrylic/Cotton/Aramid/PA/AST (Fabric Code on the booklet: FZ-MCX 200R)
GARMENT CONSTRUCTION
Aramid high tenacity FR thread
All metal thermally protected from the skin -Bar-tacked at all stress points
Protective standard collar with velcro
Heavy0duty brass zipper on aramid tape, no logo on the zipper puller
Two-way #5 zipper at CF
Storm guard over front zipper with snaps closure -Action back for mobility
Side elasticized waist
Separate arm cuffs with snap closures
Snap-on bottom
POCKETS
2 flap chest patch pockets with velcro closure, pencil slot on the left chest pocket
2 waist patch pockets with side access
2 rear hip patch pockets Red -Pen pocket on left sleeve
Tool pocket on the right leg
HIGH-VISIBILITY TRIM
4” TR69 YSY reflective tape
Double stitching on the tape
Reflective tapes over the shoulder, around the waist, arms & legs, striping “X” on back
PPE STANDARDS
Protective flame retardant suits described in this technical standard are used in noxious and hazardous environments must meet the following safety and visibility standards:
CAT 2
ATPV 9 cal/cm2 (electric arc flash rating)
US standards: NFPA 70E, ASTM F1506, Material is UL Recognized per NFPA 2112-2023 (PHEN-MCX200R, MH49121 UL file Vol 2)
